Wossner Piston Kit WO-8072-D_ – Yamaha YZ125 2002–2004
Wossner Piston Kit WO-8072-DC – Yamaha YZ125
The Wossner WO-8072-DC Piston Kit is a premium forged graded replacement piston designed for Yamaha YZ125 two-stroke motocross motorcycles. Part of Wossner's Standard Series, this piston features a lightweight single-ring design with intake window and precision graded sizing for accurate piston-to-cylinder clearance.
Vehicle Applications
- Yamaha YZ125: 2002–2004
Specifications
- Part Number: WO-8072-DC
- Bore Size: 54.02 mm
- Piston Diameter: 53.96 mm
- Size: +0.02 mm
- Piston Clearance: 0.06 mm
- Compression Height: 28.00 mm
- Stroke: 54.50 mm
- Ring Configuration: Single Ring
- Piston Ring: RSB5400
- Wrist Pin: WP032
- Wrist Pin Diameter: 15 mm
- Circlips: CW15
- Connecting Rod Length: 105.00 mm
- Connecting Rod: P2017
- Small End Bearing: N1047
- Gasket Kit: C7853 2001-2002 / C7936 2003-2004
- Piston Design: Standard Series – Single Ring – With Intake Window
Features
- Premium forged aluminium construction
- Lightweight single-ring design
- +0.02 mm graded size
- Intake window piston configuration
- Precision manufactured for accurate cylinder clearance
Important: Always accurately measure the cylinder and confirm the correct piston grade before installation. Professional installation is recommended.
Disclaimer: Product images are for illustration purposes only and may differ from the actual product supplied. Vehicle applications and specifications are provided as a guide only. It is the purchaser's responsibility to confirm the part number, dimensions and fitment are correct before installation.
