Wossner Piston Kit WO-8075-D150 – Yamaha YFZ350 Banshee

The Wossner WO-8075-D150 Piston Kit is a premium forged +1.50 mm oversize piston listed in the Wossner master data for the Yamaha YFZ350 Banshee. It features a durable Standard Series dual-ring design with reed holes.

Vehicle Applications

• Yamaha YFZ350 Banshee: 1987–2006

Specifications

• Part Number: WO-8075-D150
• Bore Size: 65.50 mm
• Piston Diameter: 65.44 mm
• Oversize: +1.50 mm
• Piston Clearance: 0.06 mm
• Compression Height: 36.00 mm
• Overall Length: 54.00 mm
• Piston Ring: RSB6550
• Wrist Pin: WP027 – 16 mm
• Circlips: CW16
• Connecting Rod: P2035
• Small End Bearing: N1017
• Gasket Kit: C7094 64.50mm / C7365 66.50mm / C7316 68.00mm / C7710 69.50mm / C7607 71.00mm
• Piston Design: Standard Series – Dual Ring – With Reed Holes

Important: Oversize pistons require accurate cylinder measurement and professional machining before installation.

Disclaimer: Product images are for illustration purposes only and may differ from the actual product supplied. Vehicle applications and specifications are provided as a guide only. It is the purchaser's responsibility to confirm the part number, dimensions and fitment are correct before installation.
